Miele Professional PRI 210
(1000mm) Professional Rotary Ironer, Height-Adjustable
Professional rotary ironer with 210mm diameter roller and 1000mm working width. Height-adjustable with touch display controls. Performance 23.5 kg/h.
- ✓Height-adjustable for ergonomic operation
- ✓Touch display for easy temperature and speed control
- ✓Favourites programme for quick access
- ✓FlexControl foot pedal for hands-free feeding
- ✓Durable heat-resistant ironing cloth
Fri 8.30am–5pm
Use the button below and we’ll call you back.
Product Overview
The Miele PRI 210 [EL STW AB] is a professional electrically heated rotary ironer with a 210 mm roller diameter and 1000 mm working width, built for sites that need consistent linen finishing in a compact, wall-positionable design.
It is available in two electrical variants: a 400v, 16A three-phase version with a maximum ironing performance of up to 30.0 kg/h, and a 230v, 16A single-phase version with a maximum ironing performance of up to 23.5 kg/h. Both figures are based on 15% residual moisture, with actual output depending on linen type, residual moisture, operator experience and site conditions.
The PRI 210 is well suited to care homes, hotels, hospitality sites, launderettes, residential facilities, private estates and other environments where flatwork such as sheets, pillowcases, table linen and similar items need a neat, professional finish without moving up to a larger industrial ironer.
At a glance
1032(h) x 1579(w) x 476(d)
230v, 16A or 400v, 16A
1000 mm working width
How a&f can support you
Buying commercial laundry equipment is about more than choosing the machine. We help you get the right Miele solution for your site from day one, and support you long after it is installed.
We can help with site survey, correct variant selection, supply, installation, commissioning, user training and long-term service support.
- ✓ Manufacturer-trained engineers
- ✓ Around £12,000 of Miele spare parts carried on each service van
- ✓ Warranty handling, annual servicing and service contracts
- ✓ Rental and finance options available alongside outright purchase
Need this machine supplied, installed and supported?
Speak to a&f about purchase, rental, installation and service contract options for this product.
Call us on 01243 55 55 25, option 1 for sales support, email sales@a-f.co.uk, or click the green button.
Features and buyer benefits
A practical overview of the features that matter most when choosing a professional rotary ironer, including linen finish quality, staff efficiency, safety, installation flexibility and the choice between single-phase and three-phase electrical supply.
1000 mm working width
Suitable for everyday flatwork finishing
The 1000 mm working width is well suited to sheets, pillowcases, table linen and similar flatwork where a neat, consistent finish is needed without moving up to a larger ironer.
210 mm roller
Compact professional ironing performance
The 210 mm roller diameter gives the PRI 210 a compact footprint while still providing a professional finishing process for suitable linen items.
Choice of power supply
230v or 400v versions available
The PRI 210 is available as a 230v, 16A single-phase model or a 400v, 16A three-phase model, allowing the correct version to be selected around the site’s available electrical supply.
Higher output option
Up to 30.0 kg/h on the 400v version
The three-phase version offers the higher stated ironing performance, making it the better choice where output and daily throughput are more important.
Single-phase flexibility
Up to 23.5 kg/h on the 230v version
The single-phase version can be useful where three-phase power is not available, while still offering professional rotary ironing for appropriate workloads.
Touch display controls
Clear operation for staff
The touch display gives operators a modern control interface, helping staff set and adjust the ironer confidently during daily use.
Favourite programmes
Faster access to common settings
Frequently used settings can be selected more easily, supporting a more consistent routine where staff are processing similar linen types each day.
Flexible working height
Better ergonomics for operators
The height-adjustable design helps improve operator comfort and supports better working posture during regular ironing tasks.
Front feed and return
Practical layout for compact rooms
Laundry is fed in and returned at the front, and the machine can be positioned against a wall, helping make better use of limited laundry room space.
Safety features
Finger guard and incorrect feed recognition
Built-in safety and monitoring features support safer operation and help reduce the risk of poor feeding during use.
Footswitch control
Hands-free operational support
The FlexControl footswitch supports practical operation while handling linen, helping the user keep better control of the ironing process.
Commercial build
Tested for professional use
Miele lists the PRI 210 with 20,000 tested operating hours, supporting confidence for commercial and professional laundry environments without presenting this as a guaranteed lifespan.
Technical specifications
Key technical details for the Miele PRI 210 [EL STW AB] rotary ironer, including variant material numbers, installation size, power requirements, ironing performance, controls and practical operating features.
| Model | Miele PRI 210 [EL STW AB] |
|---|---|
| Product type | Professional electrically heated rotary ironer |
| Range | Miele Professional |
| 230v material number | 11741270 |
| 400v material number | 11741260 |
| Finish | Iron grey |
| External dimensions | H 1032 mm W 1579 mm D 476 mm |
|---|---|
| Net weight | 122 kg |
| Roller diameter | 210 mm |
| Working width | 1000 mm |
| Installation layout | Laundry infeed and outfeed at the front |
| Wall positioning | Can be set up against a wall |
| Power Required, 230v version | 230v, 16A Material number: 11741270 |
|---|---|
| Power Required, 400v version | 400v, 16A Material number: 11741260 |
| 230v total connected load | 3.40 kW |
| 400v total connected load | 5.00 kW |
| 230v heater rating | 3.00 kW |
| 400v heater rating | 4.50 kW |
| Heating type | Electric |
| 230v performance | Up to 23.5 kg/h at 15% residual moisture |
|---|---|
| 400v performance | Up to 30.0 kg/h at 15% residual moisture |
| Minimum ironing speed | 1.5 m/min |
| Maximum ironing speed | 4.0 m/min |
| Temperature control | Infinitely variable |
| Tested operating hours | 20,000 hours |
Miele performance figures are based on 15% residual moisture. Actual output depends on linen type, residual moisture, operator experience and site conditions.
| Control system | Touch display |
|---|---|
| Programme settings | Defined programme parameters |
| Favourite programmes | Available |
| Foot control | FlexControl footswitch |
| Operator ergonomics | Height-adjustable, optional plinth and option of ironing when seated |
| Laundry handling | Feed-in board, airing bar, pick-off bands and laundry return feed |
| Heater plate material | Aluminium |
|---|---|
| Padding | Supple steel wool |
| Ironer cover | ARAMID needle-felt cloth |
| Safety features | Automatic finger guard and incorrect feed recognition |
| Operating features | Air suspension, pause function and high contact pressure |
| Maintenance support | Clean and wax heater plate indicator, APRI 319 care set included |
| Connection options | Optional payment system and peak-load negotiation / energy management |
| Standards and symbols | CE, UKCA, VDE, VDE-EMC, EAC, RCM, WEEE and Machinery Directive 2006/42/EC |
Choosing the right machine
Is the Miele PRI 210 [EL STW AB] the right model for me?
The Miele PRI 210 [EL STW AB] is a compact professional rotary ironer for sites that need a consistent finish on flatwork such as sheets, pillowcases, table linen and similar items. It is most suitable where the laundry volume justifies a rotary ironer, but where space, staffing or linen volume do not require a larger industrial model.
The main choice is between the 230v, 16A single-phase version and the 400v, 16A three-phase version. The 400v model gives the higher stated ironing performance, while the 230v model may be useful where three-phase power is not available.
When is this ironer a good fit?
The PRI 210 is a good fit where a site needs a professional finish for regular flatwork, but does not need the size or output of a larger commercial laundry ironer.
- Suitable for care homes, hotels, hospitality sites, launderettes, residential facilities and private estates.
- Useful where linen presentation matters, but hand ironing is too slow or inconsistent.
- Best suited to flatwork such as sheets, pillowcases, table linen and similar items.
- Suitable where front feed and return helps staff operate in a compact laundry room.
- Can be positioned against a wall, helping make better use of available space.
What should I check before choosing this model?
The main checks are linen type, expected throughput, available space, staff training and electrical supply. A rotary ironer is very effective for suitable flatwork, but it is not the right solution for every laundry process.
- Confirm that the 1000 mm working width is suitable for the linen being processed.
- Check whether the site has 230v single-phase or 400v three-phase power available.
- Allow safe working space in front of the machine for feeding and receiving linen.
- Consider whether staff will need training on feeding technique, temperature setting and safe operation.
- Check that laundry is prepared correctly before ironing, including suitable residual moisture and folding or handling routines.
When might another model be better?
A different model may be better where the site processes larger linen, higher daily volumes or needs a wider working width. The PRI 210 is a compact professional rotary ironer, not the highest-output option in the Miele ironer range.
- Consider a wider ironer if the site processes larger sheets, wide table linen or higher volumes of flatwork.
- Consider the 400v version rather than the 230v version where higher throughput is important and three-phase power is available.
- Consider a different finishing solution if the main workload is garments, shaped items or items that are not suited to rotary ironing.
- Review the full laundry flow if washing and drying output is much higher than this ironer can comfortably finish.
Services, utilities and installation checks
The PRI 210 is electrically heated and is available in two power versions. Selecting the correct version at quotation stage is important because the material number, connected load and stated performance differ between the 230v and 400v models.
- 230v, 16A version: material number 11741270, total connected load 3.40 kW.
- 400v, 16A version: material number 11741260, total connected load 5.00 kW.
- External dimensions: 1032(h) x 1579(w) x 476(d) mm.
- Net weight: 122 kg.
- Working width: 1000 mm, roller diameter: 210 mm.
- Installation should allow safe staff access, correct positioning and future servicing.
Replacing an older model?
If the PRI 210 is being considered as a replacement for an older rotary ironer, the key checks are working width, power supply, available space, operator routine and whether the site needs the higher-output 400v version.
The current a&f historic model source does not list a direct previous-version mapping for the PRI 210. It does list older compact and small-format Miele ironer references against related current ironer ranges, including PRI120, HM21-100, CM900/902 and CM870/872. These should be treated as search and comparison terms, not confirmed direct replacements for the PRI 210.
Related older Miele ironer search terms to check when reviewing a replacement: PRI120, HM21-100, CM900/902, CM870/872. Direct PRI 210 historic mapping should be confirmed before publishing if a precise previous-version claim is needed.
Compliance, safety and environment
The PRI 210 includes safety and operating features intended to support professional use, but staff training and correct working practice remain important. Operators should understand safe feeding, finger guard function, temperature selection and routine care.
- Automatic finger guard and incorrect feed recognition are listed features.
- FlexControl footswitch supports practical operation while handling linen.
- The clean and wax heater plate indicator supports routine care of the heater plate.
- The datasheet lists CE, UKCA, VDE, VDE-EMC and Machinery Directive 2006/42/EC compliance.
- For care, hospitality or healthcare-related sites, the ironing process should be considered as part of the wider laundry handling and hygiene procedure.
Need help checking suitability?
Contact us for a free specification check or site visit before ordering. Call us on 01243 55 55 25, option 1 for sales support, or email sales@a-f.co.uk.
Product downloads
Helpful documents for this machine
Download the key documents for the Miele PRI 210 rotary ironer below. These include the operating instructions for the PRI ironer range and the product sheets for both the 230v and 400v electrical variants. If you need help confirming which version is right for your site, contact a&f and we will be happy to help.
Miele PRI 210 operating instructions
Manufacturer guidance covering operation, safety, programme use, routine care and user instructions for the Miele PRI 210, PRI 214 and PRI 217 rotary ironer range.
Miele PRI 210 product sheet, 230v
Product information for the 230v, 16A single-phase PRI 210 variant, including material number, dimensions, power requirements, ironing performance and core features.
Miele PRI 210 product sheet, 400v
Product information for the 400v, 16A three-phase PRI 210 variant, including material number, dimensions, power requirements, ironing performance and core features.
Need help choosing between the 230v and 400v versions?
The 230v version may suit sites without three-phase power, while the 400v version offers the higher stated ironing performance. If you need help checking the right variant, installation requirements or suitability for your laundry room, call us on 01243 55 55 25, option 1 for sales support, or email sales@a-f.co.uk.
